16 PORT GIGABIT POE+ MGD SWITCH

Provides power and data connection for up to 16 PoE network devices
Save installation cost by delivering data and power over existing network cables
10/100/1000 auto-sensing ports automatically detect optimal network speeds
Two small form-factor pluggable GBIC module slots (SFP)
IEEE 802.3at/af-compliant RJ45 PoE/PoE+ output ports
Power output up to 30 watts per port*
PoE power budget of 374 watts
36 Gbps switch fabric
Supports IEEE 802.3at and IEEE 802.3af-compliant PoE devices (wireless access points, VoIP phones, IP cameras, etc.)
Supports IEEE 802.3at/af detection and short circuit, overload and high-voltage protection
All RJ45 ports with Auto-MDIX and NWay auto-negotiation support
Complies with the IEEE 802.3az (Energy Efficient Ethernet EEE) specification
PoE management functions include PoE port settings, priority, power-on delay, scheduled PoE device restart and PoE device monitoring
SNMP Management and Remote Monitoring (RMON)
SNMP V1, V2C, V3 with RMON groups 1, 2, 3 & 9
IPv4/v6 dual protocol
Supports VLAN (tag-based and port-based)
Provides IEEE 802.1x port-based security
Supports link aggregation (trunking)
Supports bandwidth control per port
Supports port mirroring
Supports two types of QoS: port-based and DSCP
Broadcast storm control with multicast packet rate settings
512 kBytes buffer memory
Supports 8k MAC address entries
Supports jumbo frames up to 9 kBytes
Supports Rapid Spanning Tree/Spanning Tree protocol
Store and forward switching architecture
Full/half duplex operation
IEEE 802.3x flow control for full duplex
Configuration via Web browser, Telnet or SSH
LEDs for power, link/activity and PoE
Two high-volume cooling fans ensure perfect ventilation
Three-Year Warranty
UPC: ITL-561198
Manufacturer: Intellinet
PartNumber: ITL-561198
