24-Port Gb Ethernet PoEplus Web-Manage

- Provides power and data connection for up to 24 PoE network devices
- Saves installation costs by delivering data and power over existing network cables
- 10/100/1000 Mbps auto-sensing ports automatically detect optimal network speeds
- Four combo small-form-factor pluggable GBIC module slots (SFP) and four RJ45 copper uplinks
- IEEE 802.3at/af-compliant RJ45 PoE/PoE+ output ports
- Power output up to 30 watts per port
- PoE power budget of 370 watts
- Supports IEEE 802.3at and IEEE 802.3af-compliant PoE devices (wireless access points, VoIP phones, IP cameras)
- Supports IEEE 802.3at/af detection and short circuit, overload and high-voltage protection
- All RJ45 ports equipped with Auto-MDIX and auto-negotiation support
- Web-based configuration
- Remote reboot/restart
- Supports SNMP management
- Supports VLAN (protocol-based and port-based)
- Supports link aggregation (trunking)
- IGMP Snooping for multicast filtering
- Supports bandwidth control per port
- Supports port mirroring
- Supports two types of QoS: IEEE 802.1p and DSCP
- Broadcast storm control with multicast packet rate settings
- Supports jumbo frames up to 9.6 kBytes
- Store and forward switching architecture
- Full/half duplex operation
- IEEE 802.3x flow control for full duplex
- Supports 8k MAC address entries
- LEDs for power, link/activity and PoE
- Two high-volume cooling fans to ensure perfect ventilation
- Includes 19" rackmount brackets
UPC: ITL-561426
Manufacturer: Intellinet
PartNumber: ITL-561426
